Forced Convection AC Variable Frequency Drive / Variable Speed Frequency Drive 60 Hz

  • 1
  • 2

Brand Name : SCHNEIDER

Model Number : ATV340U75N4

Certification : CE

Place of Origin : FRANCE

MOQ : 1 PCS

Price : consult for best discount

Payment Terms : T/T, , Western Union,Paypal,, MoneyGram,, L/C

Supply Ability : 100

Delivery Time : 2-15 days

Packaging Details : schneider original package

type : Variable speed drive

application : Machine

type of cooling : Forced convection

network number of phases : 3 phase

rated supply voltage : 380 to 480 V

supply frequency : 50 60 Hz

Contact Now

    Schneider ATV340 Series Variable Frequency Drive Inverter Three Phases Drives AC Inverter

Applications

Designed for optimized installation, the Altivar Machine ATV340 drive offers cutting edge application control and advanced, easy to integrate automation capabilities. Its innovative features make it the drive of choice for OEMs entering – and rising to the challenges of – the smart machine era. The Altivar Machine ATV340 variable speed drives offer top level automation capabilities and outstanding motor control technology combined with simplicity. Altivar Machine ATV340 was engineered to maximize machine performance, reduce machine build time and sustain machine productivity.

Features
The Altivar Machine 340 is a powerful drive that aims to match your machine’s motor capabilities with maximum torque and speed performance. With an optimized speed bandwidth up to 400 Hz, the Altivar Machine 340 is designed for dynamic applications that may require faster acceleration or settling time.
  • The Altivar Machine 340 frequency inverters are very robust for high overloads, adaptable to the needs of demanding applications up to 220% nominal torque.
  • To meet the adaptability and the scalability your machine requires, Altivar Machine 340 is compatible with a wide range of motors such as asynchronous (IE2, IE3); synchronous; reluctance motors (IE4, IE5) for various applications in closed; and open loop.
Unprecedented automation performance
The Altivar Machine 340 will bring your machine to the next level of automation reaction time. Its real-time capabilities achieve the best possible machine control. The combination of ATV340 minimum application reaction time (1ms task cycle) and Ethernet connectivity in real-time, maximize your machine throughput.

Reduced machine design time

The Altivar Machine 340 will help you reduce your engineering time at every stage of the process so your machine is up and running sooner.

Simplified machine engineering
The Altivar Machine 340 accommodates numerous functions and features to simplify the machine design and reduces the engineering time from selection to commissioning.

  • Enriched variety of interfaces, numerous I/Os, Multi Ethernet protocol, PTI/PTO, embedded encoder as well as multiple option interfaces offers maximum flexibility in architecture design
  • Simple master slave configuration, positioning mode, integrated application functions facilitate and fulfill application performance for hoisting, material handling, material working and packaging machines.
Seamless automation integration
Ready-to-use EcoStruxure Machine application libraries that are Tested Validated and Documented (TVDA), combined with Ethernet services available in Altivar Machine 340 will facilitate your machine design and help you significantly reduce design time.
  • The ONE button auto-tuning for motor identification gives users the possibility to replicate the complete project in a fast and seamless manner ensuring maximum productivity in machine commissioning and production.

Sustained machine operation

Robust design for long-lasting operation and reliable service
Altivar Machine 340 has been designed to fulfil application requirements for harsh environments, such as vibration, shock and non-conductive dust and where high temperature resistance up to 60°C is needed.



Datasheet of Schneider ATV340 Series Variable Frequency Drive Inverter

range of product
Altivar Machine ATV340

product or component type
Variable speed drive

device application
Machine

device short name
ATV340

variant
Standard version

product destination
Asynchronous motors
Synchronous motors

mounting mode
Cabinet mount

EMC filter
Integrated with 20 m motor cable maxi conforming to EN/IEC 61800-3 category C3

IP degree of protection
IP20 conforming to IEC 61800-5-1
IP20 conforming to IEC 60529

type of cooling
Forced convection

supply frequency
50...60 Hz +/- 5 %

network number of phases
3 phases

[Us] rated supply voltage
380...480 V - 15...10 %

motor power kW
11 kW (normal duty)
7.5 kW (heavy duty)

motor power hp
15 hp (normal duty)
10 hp (heavy duty)

line current
25.6 A at 380 V without line choke (heavy duty)
20.4 A at 480 V without line choke (heavy duty)
22 A at 380 V with external line choke (normal duty)
17.7 A at 480 V with external line choke (normal duty)
14.6 A at 380 V with external line choke (heavy duty)
12.1 A at 480 V with external line choke (heavy duty)

prospective line Isc
22 kA

apparent power
17 kVA at 480 V (normal duty)
17 kVA at 480 V (heavy duty)

continuous output current
16.5 A at 4 kHz (heavy duty)
24 A at 4 kHz (normal duty)

maximum transient current
24.8 A during 60 s (heavy duty)
26.4 A during 60 s (normal duty)
32.4 A during 2 s (normal duty)
29.7 A during 2 s (heavy duty)

asynchronous motor control profile
Constant torque standard
Variable torque standard
Optimized torque mode

synchronous motor control profile
Permanent magnet motor
Reluctance motor

speed drive output frequency
0.1...599 Hz

nominal switching frequency
4 kHz

switching frequency
2...16 kHz adjustable
4...16 kHz with derating factor

safety function
STO (safe torque off) SIL 3

Forced Convection AC Variable Frequency Drive / Variable Speed Frequency Drive 60 Hz
